1 Outline
1.3.1 Ratings
1-4
(4) SGDV with Three-phase, 400-V Rating
∗ Refer to 3.7 Connecting Regenerative Resistors for details.
SGDV
(Three Phase, 400 V)
1R9 3R5 5R4 8R4 120 170 210 260 280 370
Continuous Output Current
[Arms]
1.9 3.5 5.4 8.4 11.9 16.5 20.8 25.7 28.1 37.2
Instantaneous Max. Output
Current [Arms]
5.5 8.5 14 20 28 42 55 65 70 85
Regenerative Resistor
*
Built-in or external External
Main Circuit Power Supply Three-phase, 380 to 480 VAC, +10% to -15%, 50/60 Hz
Control Power Supply 24 VDC ±15%
Overvoltage Category III
To Next Page
