3.1 Main Circuit Wiring
3-11
3
Wiring and Connection
3.1.3 Using the SERVOPACK with Single-phase, 200 V Power Input
Some models of Σ-V series three-phase 200 V power input SERVOPACK can be used also with a single-phase
200 V power supply.
The following models support a single-phase 200-V power input.
SGDV-R70A, -R90A, -1R6A, -2R8A, -5R5A
When using the SERVOPACK with single-phase, 200 V power input, set parameter Pn00B.2 to 1.
There is no need to change the parameter for a SGDV-120A11A008000 SERVOPACK because it uses a sin-
gle-phase 200 V power supply.
(1) Parameter Setting
 Single-phase Power Input Selection
(2) Main Circuit Power Input Terminals
Connect a single-phase 200 V power supply of the following specifications to L1 and L2 terminals.
The specifications of the power supplies other than the main circuit power supply are the same as for three-
phase power supply input.
∗1. Do not use L3 terminal.
∗2. The official model number is SGDV-120A11A008000.
Parameter Meaning
When
Enabled
Classification
Pn00B
n.0
[Factory setting]
Enables use of three-phase power supply for three-phase
SERVOPACK.
After restart Setup
n.1
Enables use of single-phase power supply for three-phase
SERVOPACK.
WARNING
• If single-phase 200 V is input to a SERVOPACK with a single-phase power input without changing the set-
ting of Pn00B.2 to 1 (single-phase power input), a main circuit cable open phase alarm (A.F10) will be
detected.
• SERVOPACK models other than those for single-phase 200-V power input do not support single-phase
power input. If a single-phase 200 V is input to the SERVOPACK that do not support single-phase power
input, the main circuit cable open phase alarm (A.F10) will be detected.
• When using a single-phase 200 V power supply, the SGDV-R70A, -R90A, -1R6A, -2R8A, or -5R5A SER-
VOPACK may not be able to produce the same servomotor torque-speed characteristics as using a three-
phase 200 V power input. Refer to the diagram of each servomotor torque-speed characteristics in
Σ -V
Series Product Catalog (No.: KAEP S800000 42).
Terminal
Symbols
Name Model SGDV-A
Specifications
L1, L2
Main circuit power in-
put terminals
R70, R90, 1R6, 2R8, 5R5
Single-phase 200 to 230 V, +10 to -15%,
50/60 Hz
120
*2
Single-phase 220 to 230 V, +10 to -15%,
50/60 Hz
L3
*1
– R70, R90, 1R6, 2R8, 5R5 None
