YASKAWA SGMSV User Manual

5 Adjustments
5.5.1 One-parameter Tuning
5-36
(1) Preparation
Check the following settings before performing one-parameter tuning.
The message “NO-OP” indicating that the settings are not appropriate will be displayed, if all of the following
conditions are not met.
• The test without a motor function must be disabled (Pn00C.0 = 0).
• The write prohibited setting (Fn010) must be set to Write permitted (P.0000).
• The tuning-less function must be disabled (Pn170.0 = 0).
• The tuning mode must be set to 0 or 1 when performing speed control.
(2) Restrictions When Using an Encoder
With this function, the following restrictions are applied in accordance with the version number of the SER-
VOPACK software and the encoder being used.
The applicable servomotor depends on the type of encoder used.
• 13-bit encoder: SGMJV-A
• 20-bit or 17-bit encoder: SGMV-D, SGMV-3
SGMPS-C, SGMPS-2
∗1. The software version number of your SERVOPACK can be checked with Fn012.
∗2. If any mode other than Tuning Mode 1 is selected, tuning will fail and result in an error.
∗3. Model following control type is not used.
∗4. Position errors may result in overshooting when positioning. The positioning time may be extended if the positioning
completed width (Pn522) is set to a small value.
∗5. Model following control type 2 can suppress overshooting resulting from position errors better than Type 1. If com-
patibility with SERVOPACK version 0007 or earlier is required, use model following control type 1 (Pn14F.0 = 0).
The control related switch (Pn14F) was added to SERVOPACK software version 0008 or later.
Software Version
*1
13-bit Encoder 20-bit or 17-bit Encoder
Mode
Model Following
Control Type
Mode
Model Following
Control Type
Version 0007 or ear-
lier
Tuning mode can be
set to only 0 or 1.
*2
–
*3
No restrictions
Type 1
*4
Version 0008 or lat-
er
No restrictions
Type 1 or 2 [Factory
setting]
*5
Parameter Function When Enabled Classification
Pn14F
n.0 Model following control type 1
After restart Tuning
n.1
[Factory setting]
Model following control type 2
