YASKAWA SGMSV User Manual

9 Troubleshooting
9-32
Absolute Encod-
er Position Differ-
ence Error (The
position saved in
the host controller
when the power
was turned OFF is
different from the
position when the
power was next
turned ON.)
Noise interference due to incorrect
cable specifications of encoder
cable.
The encoder cable must be tinned
annealed copper shielded twisted-
pair or screened unshielded twisted-
pair cable with a core of 0.12 mm
2
min.
Use the specified encoder cable.
Noise interference due to length of
encoder cable.
Check the length of the encoder
cable.
The encoder cable must be no more
than 50 m.
Noise interference due to damaged
encoder cable.
Check if the encoder cable is bent
and the sheath is damaged.
Replace the encoder cable and cor-
rect the cable layout.
Excessive noise to the encoder
cable.
Check if the encoder cable is bun-
dled with a high-current line or near
a high-current line.
Correct the cable layout so that no
surge is applied.
FG potential varies because of
influence of machines such as weld-
ers at the servomotor.
Check if the machines are correctly
grounded.
Ground machines correctly, and
prevent diversion to the FG on the
encoder side.
SERVOPACK pulse counting error
due to noise interference
Check if there is noise interference
on the I/O signal line from the
encoder.
Take measures against noise in the
encoder wiring.
Excessive vibration and shock to
the encoder
Check to see if the machine is
vibrating.
Also, check the installation condi-
tions of the servomotor (flange face
accuracy, anchoring condition, and
centering).
Reduce vibration from the machine,
or secure the servomotor installa-
tion.
An encoder fault occurred. − Replace the servomotor.
A SERVOPACK fault occurred. − Replace the SERVOPACK.
Host controller rotational serial data
reading error
Check the error detection section of
the host controller.
Correct the error detection section
of the host controller.
Check if the host controller is exe-
cuting data parity checks.
Perform a parity check on the rota-
tional serial data.
Check noise in the cable between
the SERVOPACK and the host con-
troller.
Implement measures against noise
and perform a parity check on the
rotational serial data again.
(cont’d)
Problem Probable Cause Investigative Actions Corrective Actions
