10 Appendix
10-16
Pn50A
2 Input Signal Selection 1 0000 to FFF1 − 1881 After restart Setup −
(cont’d)
Parameter
No.
Size Name
Setting
Range
Units
Factory
Setting
When
Enabled
Classification
Reference
Section
Reserved (Do not change.)
Reserved (Do not change.)
Reserved (Do not change.)
P-OT Signal Mapping
Reference
Section
0 Forward run allowed when CN1-13 input signal is ON (closed).
4.3.2
1 Forward run allowed when CN1-7 input signal is ON (closed).
2 Forward run allowed when CN1-8 input signal is ON (closed).
3 Forward run allowed when CN1-9 input signal is ON (closed).
4 Forward run allowed when CN1-10 input signal is ON (closed).
5 Forward run allowed when CN1-11 input signal is ON (closed).
6 Forward run allowed when CN1-12 input signal is ON (closed).
7 Forward run prohibited.
8 Forward run allowed.
9 Forward run allowed when CN1-13 input signal is OFF (open).
A Forward run allowed when CN1-7 input signal is OFF (open).
B Forward run allowed when CN1-8 input signal is OFF (open).
C Forward run allowed when CN1-9 input signal is OFF (open).
D Forward run allowed when CN1-10 input signal is OFF (open).
E Forward run allowed when CN1-11 input signal is OFF (open).
F Forward run allowed when CN1-12 input signal is OFF (open).
4th 3rd 2nd 1st
digit digit digit digit
n.

