10 Appendix
10-20
Pn511
2 Input Signal Selection 5 0000 to FFFF − 6543 After restart Setup 3.3.1
(cont’d)
Parameter
No.
Size Name
Setting
Range
Units
Factory
Setting
When
Enabled
Classification
Reference
Section
Homing Deceleration Switch Signal Mapping (/DEC)
0 Active when CN1-13 input signal is ON (closed).
1 Active when CN1-7 input signal is ON (closed).
2 Active when CN1-8 input signal is ON (closed).
3 Active when CN1-9 input signal is ON (closed).
4 Active when CN1-10 input signal is ON (closed).
5 Active when CN1-11 input signal is ON (closed).
6 Active when CN1-12 input signal is ON (closed).
7 Always active.
8 Always not active.
9 Active when CN1-13 input signal is OFF (open).
A Active when CN1-7 input signal is OFF (open).
B Active when CN1-8 input signal is OFF (open).
C Active when CN1-9 input signal is OFF (open).
D Active when CN1-10 input signal is OFF (open).
E Active when CN1-11 input signal is OFF (open).
F Active when CN1-12 input signal is OFF (open).
External Latch Signal Mapping (/EXT1)
0 to 3 Always not active.
4 Active when CN1-10 input signal is ON (closed).
5 Active when CN1-11 input signal is ON (closed).
6 Active when CN1-12 input signal is ON (closed).
7 to C Always not active.
D Active when CN1-10 input signal is OFF (open).
E Active when CN1-11 input signal is OFF (open).
F Active when CN1-12 input signal is OFF (open).
External Latch 2 Signal Mapping (/EXT2)
0 to F Same as /EXT1 signal mapping.
External Latch 3 Signal Mapping (/EXT3)
0 to F Same as /EXT1 signal mapping.
4th 3rd 2nd 1st
digit digit digit digit
n.

