Yealink SIP-T46G Administrator's Guide

Configuring Advanced Features
159
VLAN Discovery via DHCP
IP phones support VLAN discovery via DHCP. When the VLAN Discovery method is set to
DHCP, the IP phone will examine DHCP option for a valid VLAN ID. The predefined
option 132 is used to supply the VLAN ID by default. You can customize the DHCP option
used to request the VLAN ID.
Procedure
VLAN can be configured using the configuration files or locally.
Configuration File
<y000000000028>.cfg
Configure VLAN for the Internet
port.
For more information, refer to
VLAN on page 317.
Configure VLAN for the PC port.
For more information, refer to
VLAN on page 317.
Configure the DHCP VLAN
discovery feature.
For more information, refer to
VLAN on page 317.
Local
Web User Interface
Configure VLAN for the Internet
port and PC port and the DHCP
VLAN discovery feature.
Navigate to:
http://<phoneIPAddress>/servl
et?p=network-adv&q=load
Phone User Interface
Configure VLAN for the Internet
port and PC port.
To configure VLAN for Internet port via web user interface:
1. Click on Network->Advanced.
2. In the VLAN block, select the desired value from the pull-down list of WAN Port
Active.
3. Enter the VLAN ID in the VID (1-4094) field.

Yealink SIP-T46G Specifications

General

Backlight	Yes
Power requirements	100-240V, DC 5V
Touchscreen	-
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	6
Voice codecs	G.711, G.722, G.723, G.726, G.729A, G.729B
Bluetooth	No
RJ-9 ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Storage temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	185 mm
Width	244 mm
Height	213 mm
