Yealink SIP-T46G Administrator's Guide

Configuring Advanced Features
167
assistance from a third-party network server (STUN server) usually located on public
Internet. The IP phone can be configured to act as a STUN client, which sends
exploratory STUN messages to the STUN server. The STUN server uses those messages
to determine the public IP address and port used, and then informs the client.
The NAT traversal and STUN server are configurable on a per-account basis.
Procedure
NAT traversal and STUN server can be configured using the configuration files or locally.
Configuration File
<MAC>.cfg
Configure the NAT traversal
and STUN server on the IP
phone.
For more information, refer to
Network Address Translation on
page 321.
Local
Web User Interface
Configure the NAT traversal
and STUN server on the IP
phone.
Navigate to:
http://<phoneIPAddress>/servl
et?p=account-register&q=load
&acc=0
To configure the NAT traversal and STUN server via web user interface:
1. Click on Account.
2. Select the desired account from the pull-down list of Account.
3. Select STUN from the pull-down list of NAT.
4. Enter the IP address or the domain name in the STUN Server field.

Yealink SIP-T46G Specifications

General

Backlight	Yes
Power requirements	100-240V, DC 5V
Touchscreen	-
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	6
Voice codecs	G.711, G.722, G.723, G.726, G.729A, G.729B
Bluetooth	No
RJ-9 ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Storage temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	185 mm
Width	244 mm
Height	213 mm
