Yealink SIP-T46G Administrator's Guide

Administrator’s Guide for SIP-T46G IP Phone
220
2. Click Start to begin capturing signal traffic.
3. Reproduce the issue to get stack traces.
4. Click Stop to end capturing.
5. Click Export to open file download window, and then save the file to your local
system.
To capture packets using the Ethernet software:
Connect the IP phone’s Internet port with the PC to the same HUB, and then use Sniffer,
Ethereal or Wireshark software to capture the packets. You can also set a mirror port in
the switch to monitor the port of the connected IP phone.
The IP phones support a troubleshooting feature called Watch Dog, which help you
monitor the IP phones status and provide the ability to automatically reboot. When the
Watch Dog feature is enabled, the IP phones will automatically reboot when it detects a
fatal failure. This feature can be configured using the configuration files or the web user
interface.
You can use the ―watch_dog.enable‖ parameter to configure the Watch Dog feature in
the configuration files. For more information, refer to Watch Dog on page 351.
To configure the Watch Dog feature via web user interface:
1. Click on Settings->Preference.

Yealink SIP-T46G Specifications

General

Backlight	Yes
Power requirements	100-240V, DC 5V
Touchscreen	-
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	6
Voice codecs	G.711, G.722, G.723, G.726, G.729A, G.729B
Bluetooth	No
RJ-9 ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Storage temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	185 mm
Width	244 mm
Height	213 mm
