Yealink SIP-T46G Administrator's Guide

Administrator’s Guide for SIP-T46G IP Phone
226
the server simultaneously. Then the server configures the Always Forward feature as
configured on the phone side. Hence, the server is able to get the right status of the
extension.
Do one of the following:
 Try to set another available IP address for the IP phone.
 Check the configuration of the network via phone user interface at the path
Menu->Advanced->Network->WAN Port. If Static IP Client is selected, select
DHCP IP Client instead.
Reset your phone to factory configurations after you have tried almost all
troubleshooting suggestions but do not resolve the problem. You need to note that all
customized settings will be overwritten after resetting. Do not power off until the phone
starts up successfully.
To reset your phone via web user interface:
1. Click on Settings->Upgrade.
2. Click Reset in the Reset to Factory Settings field.
The web user interface prompts the message ―Do you want to reset to factory?‖.
3. Click OK to confirm the resetting.
The phone will be reset to factory sucessfully after startup.
Note
Reset of the phone may take a few minutes. Do not power off until the phone starts up
successfully.

Yealink SIP-T46G Specifications

General

Backlight	Yes
Power requirements	100-240V, DC 5V
Touchscreen	-
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	6
Voice codecs	G.711, G.722, G.723, G.726, G.729A, G.729B
Bluetooth	No
RJ-9 ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Storage temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	185 mm
Width	244 mm
Height	213 mm
