• Event Data
• Sample rate
Select the data recording interval. Use the table under “Data length” for reference.
• Mode
Setting Description
Free Records data continuously.
Single Records data when a trigger condition is met.
Repeat Records data whenever a trigger condition is met.
• Data length
Set the size of recorded data les. Recorded data is divided into les of the size
specied here. The data lengths that you can set here vary depending on the
Sample rate setting.
Sample rate
1
25ms
2
125ms 250ms 500ms 1s
Selectable data
lengths
10 min to 4 h 10 min to 1
day
10 min to 2
days
10 min to 3
days
10 min to 7
days
Sample rate
1
2s 5s 10s 30s 1min
Selectable data
lengths
10 min to 14
days
10 min to 31
days
10 min to 31
days
1 h to 31 days 1 h to 31 days
Sample rate
1
2min 5min 10min
Selectable data
lengths
1 h to 31 days 1 h to 31 days 1 h to 31 days
1 You cannot choose an interval that is faster than the scan interval.
2 Only available on high-speed input models of the MV.
• Pre-trigger
Select the amount of data before each trigger activation that you want to record.
You can select 0, 5, 25, 50, 75, 95, or 100% of the set Data length. If you do not
want to record any data before trigger activations, choose 0%.
• Trigger signal > Key
To activate a trigger with key operations, select On.
Note
• You can activate triggers with the event action function (see section 7.1 for details).
• If a trigger condition is met when the START/STOP key is pressed, recording will begin.
