4-8
IM MV1000-01E
• Text Field
Press MENU and then select > Menu tab > Data save > File settings > Batch text.
Settings
• Batch > On/Off
Select On to use the batch function.
• Batch > Lot-No. digit
You can set the lot number to 4, 6, or 8 digits. Select Off to disable lot numbers.
• Batch > Auto increment
Setting Description
On Automatically sets the lot number of the next measurement to the current lot
number + 1.
Off Turns auto increment off.
• Data file name > Structure
Batch: Creates display and event data lenames by combining the batch number
with the serial number.
For an explanation of the le naming function, see section 1.5.
• Data file name > Identified strings
For an explanation of the le naming function, see section 4.2.
• Text field number
Select a number from 1 to 8.
• Text field number > Title of field, Text field number > Characters
Enter a character string.
Title of eld: Up to 20 characters,
A
a
# 1
. Characters: Up to 30 characters,
A
a
# 1
.
4.3 Using the Batch Function
