Procedure
• Switching the Trend Interval
1.
In Operation Mode, press FUNC.
The function menu appears.
2.
Press the Second speed soft key or the Normal speed soft key.
The trend display update interval is changed. A message appears on the trend display (when
the MV is configured to write a message).
Display example: 10:53 1min/div
Note
You can also switch the trend interval by using the event action function. For event action
configuration instructions, see chapter 7.
6.3 Setting the Secondary Trend Interval
