Settings
• Message
• Write group
This setting applies only to messages that are written using keys.
Setting Description
Common Writes messages to all groups.
Separate Writes messages to the displayed group.
• Power-fail message
See section 6.16 for details.
• Change message
See section 6.3 for details.
• Message No.
Select a message number (1 to 100). Message numbers 1 to 10 are used for free
messages.
*
If you set a free message, the corresponding message number will be
overwritten.
* Messages that are created and written on the spot.
• Message > Characters
Set the message (up to 32 characters,
).
Procedure
• Writing a Message
You cannot write a message when memory sampling has stopped.
1.
Display the group that you want to write a message to.
• Even when Write group is set to Separate, a message is written to all groups if the MV is
showing a display unrelated to a group (such as the overview display). When the MV is
showing a 4-panel display, a message is written to the displayed group.
• When Write group is set to Common, a message is written to all groups.
2.
Press FUNC.
The function menu appears.
3.
Press the Message soft key.
4.
Press the soft key corresponding to the desired message number range (example:
[1-10]).
A list of messages appears.
6.4 Writing a Message
