10-3
IM MV1000-01E
Computation and Report Functions (/M1 and /PM1 options)
1
2
3
4
5
6
7
8
9
10
11
12
13
App
Index
Settings
• First-CH, Last-CH
Select the target channels.
• Calculation expression, span
• Math On/Off
Select On for channels that you want to use.
• Calculation expression
Set the expression by using up to 120 characters.
For instructions on how to write expressions, see section 10.2.
MV1000
Press the Input soft key to open a window for entering an expression.
Press the M1/M2 soft key to switch between a screen used to enter values and
characters and a screen used to enter operators and functions. Use soft keys,
arrow keys, and DISP/ENTER to enter an expression.
MV2000
Press the Input soft key to open a window used to enter an expression.
Note
You cannot simultaneously use a USB keyboard and the keys on the MV to enter an
expression. If you press an MV soft key while entering an expression from a USB keyboard, the
expression will be cleared.
10.1 Configuring Computation Channels
To Next Page
