1-21
IM MV1000-01E
Feature Overview
1
2
3
4
5
6
7
8
9
10
11
12
13
App
Index
Memory Summary
You can display a list of the display and event data that is stored in internal memory.
• You can select a display data or event data entry to access its historical trend display.
• The MV displays the number of manually sampled data and report data (/M1 and
/PM1 options) samples.
For operating instructions, see section 5.9.
To the historical trend display
Cursor (selects a file)
Memory start date and time
Memory stop date and time
Sampling count
Status
Internal memory data files/
maximum number of recordable files
Date and time of the most recently
recorded data
Data type
• Display data
• Event data
• Switching Displayed Items
You can switch between two lists of information.
• Start and stop times
• File names
• Data Storage
You can save the data in the internal memory to a CF card or to USB ash memory.
1.4 Display
To Next Page
