YOKOGAWA wt3000 User Manual

7-13
IM 760301-01E
1
2
3
4
5
6
7
8
9
10
11
12
App
Index
Trend Display
Explanation
The trends can be assigned to the divided windows.
• Selecting the Number of Screen Divisions
Select the number of divisions of the screen from the choices below. This is the same
as with the waveform display (section 6.6).
• Single: No division
• Dual: 2 divisions
• Triad: 3 divisions
• Quad: 4 divisions
The number of displayed points in the vertical direction of one divided window varies
depending on the number of divisions as follows:
Single: 432 points, Dual: 216 points, Triad: 144 points, Quad: 108 points
• Waveform Mapping
The trends that are turned ON (see section 7.2) are assigned in order according to the
trend number (T1 to T16) to the divided windows. This corresponds to the “Auto”
setting for the waveform display.
7.6 Displaying Trends on Divided Windows
