YOKOGAWA wt3000 User Manual

12-15
IM 760301-01E
1
2
3
4
5
6
7
8
9
10
11
12
12
App
Index
Specifications
12.10 GP-IB Interface
Item Specifications
Devices That Can Be Used NATIONAL INSTRUMENTS
• AT-GPIB
• PCI-GPIB and PCI-GPIB+
• PCMCIA-GPIB and PCMCIA-GPIB+
Driver: NI-488.2M Ver. 1.60 or later
Electrical and mechanical Conforms to IEEE St’d 488-1978 (JIS C 1901-1992).
specifications
Functional specifications SH1, AH1, T6, L4, SR1, RL1, PP0, DC1, DT1, and C0
Protocol Conforms to IEEE St’d 488.2-1992
Code used ISO (ASCII) code
Address 0 to 30
Clear remote mode Remote mode can be cleared by pressing LOCAL (except during Local Lockout).
For details on the specifications of the GP-IB interface, see the Communication Interface User’s Manual (IM760301-17E) .
12.11 Safety Terminal Adapter
Item Specifications
Maximum allowable current 36 A
Withstand voltage 1000 V CAT III
Contact resistance 10 mΩ or less
Contact section Nickel plating on brass or bronze
Insulator Polyamide
Core wire Maximum diameter 1.8 mm
Insulation thickness Maximum diameter 3.9 mm
