Item Setting
MOTOR SET (displayed on models with the motor evaluation function on the motor version)
Scaling (Speed) 1.0000
Scaling (Torque) 1.0000
Scaling (Pm) 1.0000
Unit (Speed) rpm
Unit (Torque) Nm
Unit (Pm) W
Analog
Auto Range (Speed) Off
Auto Range (Torque) Off
Range (Speed) 20V
Range (Torque) 20V
Line Filter Off
Sync Source None
Pulse
Range Upper (Speed) 10000.0000
Range Upper (Torque) 50.0000
Range Lower (Speed) 0.0000
Range Lower (Torque) -50.0000
Rated Upper (Torque) 50.0000
Rated Upper (Rated Freq) 15000 Hz
Rated Lower (Torque) -50.0000
Rated Lower (Rated Freq) 5000 Hz
Pulse N (Speed) 60
Sync Speed
Pole 2
Source I1
PRINT MENU (applies to models with the built-in printer option)
Print to Built-in
Print Format Hard Copy
D/A Output (applies to models with the D/A output option)
Item No. Function Element/S Order Range Mode
1UElement 1 – Fixed
2I Element 1 – Fixed
3PElement 1 – Fixed
4SElement 1 – Fixed
5QElement 1 – Fixed
6l Element 1 – Fixed
7f Element 1 – Fixed
8fUElement 1 – Fixed
9fIElement 1 – Fixed
10 to 20 – – – Fixed
Appendix 2 List of Initial Settings and Display Order of Numeric Data
