YOKOGAWA wt3000 User Manual

App-8 IM 760301-01E
tem Setting
CURSOR (for Wave)
Wave Cursor Off
Wave C1 Trace U1
Wave C2 Trace I1
Cursor Path Max
Wave C1 + 10.0 ms
Wave C2 × 40.0 ms
CURSOR (for Bar, displayed on models with the advanced computation (/G6) or harmonic
measurement (/G5) option)
Bar Cursor Off
Bar C1 + 1 order
Bar C2 × 15 order
CURSOR (for Trend)
Trend Cursor Off
Trend C1 Trace T1
Trend C2 Trace T2
Trend C1 + 100
Trend C2 × 900
Cursor (for MATH, displayed on models with the advanced computation (/G6) option)
Common to Cursor (for Wave)
Cursor (for FFT, displayed on models with the advanced computation (/G6) option)
Trend Cursor Off
Trend C1 Trace T1
Trend C2 Trace T2
Trend C1 + 100
Trend C2 × 900
HRM SET
Freq Band Normal
PLL Source U1
Min Order 1
Max Order 100
Thd Formula 1/Total
STORE
Store Status Off
STORE SET
Mode Store
Store To Memory
Store Settin
Mode Manual
Count 100
Store Interval 00:00:00
Store Item Numeric
List Item Element1
U, I, P, S, Q, λ, φ, FreqU, FreqI
FILE
File Item Setup
IMAGE SAVE
Format TIFF
Color Off
AUTO Naming ON
NULL
Null Off
Appendix 2 List of Initial Settings and Display Order of Numeric Data
