YOKOGAWA wt3000 User Manual

App-7
IM 760301-01E
1
2
3
4
5
6
7
8
9
10
11
12
App
App
Index
Appendix
Item Setting
FORM (for FFT, displayed on models with the advanced computation (/G6) option)
Format Single
FFT Points 20k
Trigger Common to FORM (for Wave)
Display Setting
Interpolate Common to FORM (for Wave)
Graticule Common to FORM (for Wave)
Scale Value Common to FORM (for Wave)
Spectrum Type Line
FFT Window Rect
Disp Start 0
Disp End 10000
Vertical Scale Log
ITEM (for flicker, displayed on models with the voltage fluctuation and flicker measurement (/FL)
option)
Display Elem. Element1
Limit Settings
Judgement
dc ON
dmax ON
d(t) ON
Pst ON
Plt ON
Limit
dc 3.30%
dmax 4.00%
d(t) 500 ms, 3.30%
Pst 1.00
Plt 0.65
Plt N value 12
FORM (for flicker, displayed on models with the voltage fluctuation and flicker measurement
(/FL) option)
Measurement Flicker
Flicker Settings
Object Element1
Un mode Auto
Un Set 230.00 V
Frequency 50 Hz
Interval 10 min 00 sec
Count 12
dmin 0.10%
ITEM (for cycle by cycle, displayed on models with the cycle-by-cycle measurement (/CC)
option)
List Item No. 1 2345
Function Freq U I P S
Element/Σ Element1 Element1 Element1 Element1 Element1
Cursor No. 1
FORM (for cycle by cycle, displayed on models with the cycle-by-cycle measurement (/CC)
option)
Sync Source U1
Sync Slope Rise
Trigger Common with FORM (for Wave)
Cycle Count 100
Time out 10
USER SET
Function1 U+peak
Function2 U-pea
Function3 I+peak
Function4 I-peak
Appendix 2 List of Initial Settings and Display Order of Numeric Data
