Item Setting
FORM (for Bar, displayed on models with the advanced computation (/G6) or harmonic
measurement (/G5) option)
Format Single
Start Order 1
End Order 100
ITEM (for Trend)
Trend Display
On T1 to T8
Trend Items
Trend Object T1
Function U
Element Element1
Order –
Trend Scale
Trend Object T1
Scaling Auto
Upper Scale 1.000E+02
Lower Scale -1.000E+02
FORM (for Trend)
Trend Format Single
Trend T/div 3 s/div
Display Setting Common to Form (for Wave)
FORM (for Vector, displayed on models with the advanced computation (/G6) or harmonic
measurement (/G5) option)
Object ΣA
Numeric On
U Mag 1.000
I Mag 1.000
ITEM (for MATH, displayed on models with the advanced computation (/G6) option)
Wave/Math Display
On Common to ITEM (for Wave)
V Zoom & Position Common to ITEM (for Wave)
Math Setup
Math1 Expression U1*I1
Scale Auto
Center 0.0000E+00
Scale/div 2.5000E+01
Unit W
Label Math1
Math2 Expression ABS(U1)
Scale Auto
Center 0.0000E+00
Scale/div 2.5000E+01
Unit V
Label Math2
Constant
K1 1.0000E+00
K2 2.0000E+00
K3 3.0000E+00
K4 4.0000E+00
K5 5.0000E+00
K6 6.0000E+00
K7 7.0000E+00
K8 8.0000E+00
FORM (for MATH, displayed on models with the advanced computation (/G6) option)
Common to FORM (for Wave)
ITEM (for FFT, displayed on models with the advanced computation (/G6) option)
FFT1 Display On
FFT1 Object FFT(U1)
FFT1 Label FFT1
FFT2 Display On
FFT2 Object FFT(I1)
FFT2 Label FFT2
