App-5
IM 760301-01E
1
2
3
4
5
6
7
8
9
10
11
12
App
App
Index
Appendix
Item Setting
S,Q Formula Type1
Pc Formula IEC76-1 (1976)
P1 and P2 of IEC76-1 (1993) P1 = 0.5000, P2 = 0.5000
Sampling Frequency Auto
Phase 180 Lead/Lag
Sync Measure Master
SYNC SOURCE
Element Object Element1 Element2 Element3 Element4
Sync Source I1 I2 I3 I4
UPDATE RATE
Update Rate 500 ms (EAMP)
HOLD
Hold Off
INTEGRATOR
Integrator Status Reset status
Integ Set
Mode Normal
Timer Setting 00000:00:00
Integ Start 2006/01/01 00:00:00
Integ End 2006/01/01 01:00:00
Auto Cal Off
D/A Rated Time 00001:00:00
(displayed when the optional D/A output is installed)
ITEM (for Numeric)
Item No. 1
Function U
Element/Σ Element1
Order –
Frequency Meas. Item U1, I1
FORM (for Numeric)
Numeric Form 4 Items
ITEM (for Wave)
Wave Display
On U1 to I4, Speed, Torque
V Zoom & Position
Element Object Element1
(U) V Zoom ×1
(U) Position 0.000%
(I) V Zoom ×1
(I) Position 0.000%
FORM (for Wave)
Format Single
Time/div 5 ms
Trigger
Mode Auto
Source U1
Slope Rise
Level 0.0%
Display Setting
Interpolate Line
Graticule Grid( )
Scale Value On
Label Off
Wave Mapping
Mode Auto
User Setting U1:0, I1:0, U2:1, I2:1, U3:2, I3:2, U4:3, I4:3,
Speed:0, Torque:0, Math1:1, Math2:1
ITEM (for Bar, displayed on models with the advanced computation (/G6) or harmonic
measurement (/G5) option.)
Bar Item No. 1 2 3
Function U I P
Element Element1 Element1 Element1
Appendix 2 List of Initial Settings and Display Order of Numeric Data

YOKOGAWA wt3000 Specifications

General

Frequency Range	DC, 0.1 Hz to 1 MHz
Number of Input Elements	Up to 4 elements
Harmonic Measurement	Up to 500th order
Interfaces	USB, Ethernet, RS-232
Sampling Rate	2 MS/s
Voltage Range	1.5 V to 1000 V
Display	8.4-inch LCD
