YOKOGAWA wt3000 User Manual

App-4 IM 760301-01E
Appendix 2 List of Initial Settings and Display Order
of Numeric Data
Initial Settings (Factory Default, Example for a Model with Four Input Elements Installed)
The default settings vary depending on the number of installed input elements and the
presence/absence of options.
Item Setting
RANGE 2-A input element 30-A input element
U Range 1000 V 1000 V
I input Terminal Direct Direct
I Direct input Range 2 A 30 A
External Sensor Range 10 V 10 V
SENSOR RATIO 10.0000 mV/A
WIRING
Wiring Setting 1P2W
η Formula
η1PΣB/PΣA
η2PΣA/PΣB
η3 Off/1
η4 Off/1
Udef1 P1+None+None+None
Udef2 P1+None+None+None
Compensation
Wiring Compensation Off
Efficiency Compensation Off
Element Independent Off
∆Measure -
SCALING
Scaling Off
Scaling Item VT
VT 1.0000
CT 1.0000
Scaling Factor 1.0000
LINE FILTER Off
FREQ FILTER Off
AVG
Averaging Off
Averaging Type Exp.
Exp. Count 2
Lin. Count 8
MEASURE
User Defined On/Off Unit Expression
Function1 Off V UMN(E1)
Function2 Off V UMN(E2)
Function3 Off V UMN(E3)
Function4 Off V UMN(E4)
Function5 Off V U(E1,ORT)
Function6 Off A I(E1,ORT)
Function7 Off V U(E1,ORT)
Function8 Off A I(E1,ORT)
Function9 Off V U(E1,ORT)
Function10 Off A I(E1,ORT)
Function11 Off V U(E1,ORT)
Function12 Off A I(E1,ORT)
Function13 Off V U(E1,ORT)
Function14 Off A I(E1,ORT)
Function15 Off V U(E1,ORT)
Function16 Off A I(E1,ORT)
Function17 Off V U(E1,ORT)
Function18 Off A I(E1,ORT)
Function19 Off V U(E1,ORT)
Function20 Off A I(E1,ORT)
Max Hold Off

YOKOGAWA wt3000 Specifications

General

Frequency Range	DC, 0.1 Hz to 1 MHz
Number of Input Elements	Up to 4 elements
Harmonic Measurement	Up to 500th order
Interfaces	USB, Ethernet, RS-232
Sampling Rate	2 MS/s
Voltage Range	1.5 V to 1000 V
Display	8.4-inch LCD
