YOKOGAWA wt3000 User Manual

12-14 IM 760301-01E
12.8 Storage
PC Card Interface
Item Specifications
Number of slots 1
Type TYPE II flash ATA card
USB Storage Device
Item Specifications
Supported USB mass USB memory (USB Mass Storage Class)
storage devices
For specification details, see the next section, “USB PERIPHERAL Interface.”
12.9 USB PERIPHERAL Interface
Item Specifications
Connector type USB type A connector (receptacle)
Electrical and mechanical Conforms to USB Rev.1.1
specifications
Data rate 12 Mbps maximum
Supported keyboards
*1
104 keyboard (US) and 109 keyboard (Japanese) conforming to USB HID Class Ver.1.1
Supported USB mass USB memory (USB Mass Storage Class)
storage devices
Power supply 5 V, 500 mA
*2
(per port)
Number of ports 2
*1 For details on the compatible USB devices, contact your nearest YOKOGAWA dealer.
*2 Devices whose maximum current consumption exceeds 100 mA cannot be connected simultaneously to the two ports.

YOKOGAWA wt3000 Specifications

General

Frequency Range	DC, 0.1 Hz to 1 MHz
Number of Input Elements	Up to 4 elements
Harmonic Measurement	Up to 500th order
Interfaces	USB, Ethernet, RS-232
Sampling Rate	2 MS/s
Voltage Range	1.5 V to 1000 V
Display	8.4-inch LCD
