8-20 IM 760301-01E
• Properties
Displays the following information about the selected file: filename.extension, the file
size, the date the file was saved, the attribute, the comment, etc.
Note
• The following data is stored in the places where numerical data does not exist when saving
the stored numerical data.
• For ASCII files: Characters NAN, +INF, -INF, ERROR, or blank
*1
.
*1 Measurement functions that are displayed as blank such as the 0th (dc) and 1st order
values of φU and φI.
• For Float files: 0x7FC00000, 0x7F800000, 0xFF800000, or 0xFFFFFFFE.
• The number of directories and files that can be displayed in the file list is 2500. If the number
of directories and files in a directory exceeds 2500, the file list randomly displays 2500 of the
directories and files.
• Files that do not have an archive attribute are not displayed in the File List window. Do not
remove the archive attribute of the files saved by the WT3000 using your PC.
• Up to 41 characters can be displayed in the path. If the path exceeds 41 characters, “...” is
displayed at the end of the character string.
• File names are not case-sensitive. Comments are case-sensitive. In addition, the following
names cannot be used due to limitations of MS-DOS.
AUX, CON, PRN, NUL, CLOCK, COM1 to COM9, and LPT1 to LPT9
• The maximum number of files that can fit in one directory is 2500. If you need to save more
than 2500 files, change the directory or move the existing files to another directory.
• You can view the stored data saved in Float format (*.WTD) using the File Reader Software
*2
on you PC and convert the data into a CSV file.
*2 The software program can be downloaded by accessing the Download and Support page
from the following URL.
http://www.yokogawa.com/tm/
• If you change the extension of the file such as on a PC, the file can no longer be loaded into
the File Reader Software.
8.5 Saving the Stored Data
To Next Page
