YOKOGAWA wt3000 User Manual

App-12 IM 760301-01E
ALL Item Display
Display Page
1
U
I
P
S
Q
λ
φ
fU(FreqU)
fI(FreqI)
2
U+pk
U-pk
I+pk
I-pk
CfU
CfI
Pc
3
Time
Wp
WP+
WP-
q
q+
q-
WS
WQ
4
η1
η2
η3
η4
∆F1
∆F2
∆F3
∆F4
Speed*
1
Torque*
1
SyncSp*
1
Slip*
1
Pm*
1
5
F1
F2
F3
F4
F5
F6
F7
F8
F9
F10
F11
F12
F13
F14
F15
F16
F17
F18
F19
F20
6*
2
U(k)
I(k)
P(k)
S(k)
Q(k)
λ(k)
φ(k)
φU(k)
φI(k)
7*
2
U(k)
I(k)
P(k)
Q(k)
Z(k)
Rs(k)
Xs(k)
Rp(k)
Xp(k)
8*
2
Uthd
Ithd
Pthd
Uthf
Ithf
Utif
Itif
hvf
hcf
9*
2
φU1-U2
φU1-U3
φU1-I1
φU1-I2
φU1-I3
Left Side of the SingleList*
2
or DualList*
2
Display
Display Page
1
U1
I1
P1
S1
Q1
λ1
φ1
Uthd1
Ithd1
Pthd1
Uthf1
Ithf1
Utif1
Itif1
2
U2
I2
P2
S2
Q2
λ2
φ2
Uthd2
Ithd2
Pthd2
Uthf2
Ithf2
Utif2
Itif2
3
U3
I3
P3
S3
Q3
λ3
φ3
Uthd3
Ithd3
Pthd3
Uthf3
Ithf3
Utif3
Itif3
4
U4
I4
P4
S4
Q4
λ4
φ4
Uthd4
Ithd4
Pthd4
Uthf4
Ithf4
Utif4
Itif4
5
UΣA
IΣA
PΣA
SΣA
QΣA
λΣA
φU1-U2
φU1-U3
φU1-I1
φU1-I2
φU1-I3
6
UΣB
IΣB
PΣB
SΣB
QΣB
λΣB
φU1-U2
φU1-U3
φU1-I1
φU1-I2
φU1-I3
7
F1
F2
F3
F4
F5
F6
F7
F8
F9
F10
F11
F12
F13
F14
F15
F16
F17
F18
F19
F20
*1 Displayed only on models with the motor evaluation function (motor version).
*2 Displayed only on models with the advanced computation (/G6) or harmonic measurement (/G5) option.
Appendix 2 List of Initial Settings and Display Order of Numeric Data
