Appendix 3 ASCII Header File Format
When waveform display data (Wave) is saved, the following two files are automatically
created in the directory.
• Waveform display data file (.wvf)
• ASCII header file (.hdr)
The ASCII header files explained here cannot be viewed on the WT3000. Use the data in
such cases as when analyzing the waveforms on your PC.
//YOKOGAWA ASCII FILE FORMAT
$PublicInfo
FormatVersion 1.11
Model WT3000
Endian Big
DataFormat Trace
GroupNumber 3
TraceTotalNumber 10
DataOffset 8192
$Group1
TraceNumber 4
BlockNumber 1
TraceName U1 I1 U2 I2
BlockSize 1002 1002 1002 1002
VResolution 1.0000000E+00 1.0000000E+00 1.0000000E+00 1.0000000E+00
VOffset 0.0000000E+00 0.0000000E+00 0.0000000E+00 0.0000000E+00
VDataType FS4 FS4 FS4 FS4
VUnit V A V A
VPlusOverData ? ? ? ?
VMinusOverData ? ? ? ?
VIllegalData ? ? ? ?
VMaxData 9.000000e+02 3.000000e+03 3.000000e+03 1.500000e+02
VMinData -9.000000e+02 -3.000000e+03 -3.000000e+03 -1.500000e+02
HResolution 2.0000000E-05 2.0000000E-05 2.0000000E-05 2.0000000E-05
HOffset 0.0000000E+00 0.0000000E+00 0.0000000E+00 0.0000000E+00
HUnit sec sec sec sec
Date 2001/06/30 2001/06/30 2001/06/30 2001/06/30
Time 07:03:03 07:03:03 07:03:03 07:03:03
$Group2
TraceNumber 4
BlockNumber 1
TraceName U3 I3 U4 I4
BlockSize 1002 1002 1002 1002
VResolution 1.0000000E+00 1.0000000E+00 1.0000000E+00 1.0000000E+00
