YOKOGAWA wt3000 User Manual

3-11
IM 760301-01E
1
2
3
4
5
6
7
8
9
10
11
12
App
Index
Before Starting Measurements
Explanation
Use the adapters that come with the WT3000 or the adapters and various sensors sold
separately for the WT3000 according to the object being wired as follows:
• Wiring to the Voltage Measurement Terminal
Voltage
measurement
target
Voltage input terminal
of the WT3000
758921
758922
758917
758923
758931
758929
VOLTAGE
±
±
CURRENT
EXT
When using the clamp-on probe that is sold separately, use it as follows:
• Wiring to the Current Measurement Terminal
96001 (voltage output type)
* The current input terminal and EXT input terminal cannot be wired (used) simultaneously.
751552 (current output type)
758917 758921
758924
Current
measurement
target
EXT input terminal
of the WT3000
Current input terminal
of the WT3000
Connecting the clamp-on probe
VOLTAGE
±
±
CURRENT
EXT
3.6 Assembling the Adapter to Be Connected to the Voltage Input Terminal
