YOKOGAWA wt3000 User Manual

3-27
IM 760301-01E
1
2
3
4
5
6
7
8
9
10
11
12
App
Index
Before Starting Measurements
Explanation
The values specified by the panel keys can be reset to the factory default values. This is
useful when you wish to clear previous settings or start the settings from scratch. For
details on the initial settings, see appendix 2, “List of Initial Settings and Display Order of
Numeric Data.”
• Settings That Cannot Be Initialized
• Date/Time settings
• Menu and message language settings
• Setting of the time difference from GMT (when the Ethernet option is installed)
• Designation of file to be displayed (Filter)
• File utility operation (Function)
• Settings related to the GP-IB communication, serial communication (option), USB
communication (option) and Ethernet communication (option).
• Initializing at Power Up
If the power switch is turned ON while holding down RESET, the WT3000 powers up
using initial settings. In this case, “Settings That Cannot Be Initialized” as indicated
above excluding the date and time are also initialized. A message indicating that
settings have been initialized is shown on the screen.
3.13 Initializing the Settings

YOKOGAWA wt3000 Specifications

General

Frequency Range	DC, 0.1 Hz to 1 MHz
Number of Input Elements	Up to 4 elements
Harmonic Measurement	Up to 500th order
Interfaces	USB, Ethernet, RS-232
Sampling Rate	2 MS/s
Voltage Range	1.5 V to 1000 V
Display	8.4-inch LCD
