4-2
IM WT5000-02EN
• When the Integration Mode Is Set to R-Normal or R-Continuous
Computation/Output tab
Set the integration conditions.
Set the integration mode.
(Normal, Continuous, R-Normal, R-Continuous)
Set the scheduled times for
real-time integration.
Note
You can also display the computation/output settings overview screen by moving the cursor on the
Computation/Output tab using the arrow keys and then pressing SET.
Setting the Integration Timer (Timer)
4.
Tap Integration Timer. The following screen appears.
When independent computation is off
Set the integration timer.
(00000 hours : 00 minutes : 00 seconds to 10000
hours : 00 minutes : 00 seconds).
When Mode is set to Normal and the integration timer is
00000 : 00 : 00, the instrument is in manual integration
mode.
When independent computation is on
Select the integration timer's setup method (Each, All).
When you select Each, you can set the integration timer
for each input element.
4.1 Setting Integration Conditions
To Next Page
