xiii
IM WT5000-02EN
Flicker Icon
Use this icon to execute voltage fluctuations/flicker measurements.
Flicker Menu
Closes the menu
Set the measurement mode
to Flicker.
Switch the element you want
to display the measurement
data of.
Scrolls the screen page
Executes initialization
Starts a measurement
Reset
Set the measurement
conditions and judgment
conditions (see section 14.1).
Normal voltage fluctuation/flicker measurement Measurement of dmax caused by manual switching
Closes the menu
Set the measurement mode
to dmax.
Switch the element you want
to display the measurement
data of.
Executes initialization
Starts a measurement
Reset
Completes the measurement and
displays the judgment
Changes the observation period
and measures again
Set the measurement
conditions and judgment
conditions (see section 14.1).
Menu Icons
To Next Page
