YOKOGAWA WT5000 User Manual

7-2
IM WT5000-02EN
Setting the Maximum Storage Count
Tap Optimize Count, which is used to set the maximum storage count. An Optimize Count
screen appears.
Confirms and optimizes the maximum storage count
Sets the storage count
The storage count is set to the maximum storage count displayed to the left.
Maximum storage count (0-the maximum number of times that data can be stored to the save
destination)
If the save destination is set to a USB memory device (drive) and you remove it, the save destination
automatically changes to internal memory. If you close this screen, tap Optimize Count, and reopen
this screen, the maximum storage count is changed to a value determined from the free space of the
internal memory.
Note
The maximum number of times that storage can be performed depends on the number of stored items that
you have set and the free space at the save destination.
For details on how to set the stored items, see section 7.2. For details on how to set the save destination,
see section 7.3.
Setting the Storage Control
• When the Storage Mode Is Manual
Computation/Output tabConfigure the storage.
Storage control setup screen (when the storage mode is Manual)
Set the storage interval (00 hours : 00 minutes : 00 seconds-99 hours : 59 minutes : 59 seconds).
Set whether to save (store) numeric
data at the start of storage.
OFF: Not be saved
ON: Saved
You cannot set this when the storage interval is set to 00:00:00.
Setting the Storage Interval
Tap Interval. An Interval screen appears.
Set the storage interval
(00 hours : 00 minutes : 00 seconds-99 hours :
59 minutes : 59 seconds).
7.1 Setting the Storage Operation

YOKOGAWA WT5000 Specifications

General

Frequency Range	DC, 0.1 Hz to 1 MHz
Number of Channels	Up to 7
Interfaces	USB, Ethernet, GP-IB, RS232
Sampling Rate	10 MS/s
Harmonic Analysis	Up to the 500th order
Weight	Approximately 15 kg
Display	10.1-inch WXGA (1280 x 800) TFT LCD
