vii
IM WT5000-02EN
Selecting the Displayed Item Number or Displayed Harmonic Data
Column
While you are changing the displayed items, you can select the displayed item or displayed harmonic
data column you want shown by tapping the measurement display screen directly with an Small menu
shown.
This is the same operation as selecting the displayed item number (on the 4-, 8-, and 16-value displays
and matrix display) and selecting the displayed harmonic data column (on the Hrm List Single or Hrm
List Dual display).
1. Tap the Item No.2 area. The Item No. display changes to 2.
2. Set the items (e.g., function).
Item No. display
Items
Measurement display screen
Small menu
Resetting the Displayed Items
Closes the menu
Set the reset pattern (Element Origin, Function Origin,
Clear Current Page, Clear All Pages).
Executes reset
Menu Icons
To Next Page
