Zebra DS3608

To Next Page

To Previous Page

CHAPTER 6 USB INTERFACE

Introduction

This chapter provides instructions for programming the digital imager to interface with a USB host. The digital

imager scanner connects directly to a USB host, or a powered USB hub. The USB host can power the digital

imager.

Throughout the programming bar code menus, default values are indicated with asterisks (

*).

*North American Standard USB Keyboard

Feature/Option

*Indicates Default
