11 - 50 DS3608 Digital Scanner Product Reference Guide

I 2 of 5 Check Digit Verification

Parameter # 49 (SSI # 31h)

Enable this feature to check the integrity of all I 2 of 5 symbols to verify the data complies with either the specified

Uniform Symbology Specification (USS), or the Optical Product Code Council (OPCC) check digit algorithm.

*Disable

(0)

USS Check Digit

(1)

OPCC Check Digit

(2)
