CHAPTER 15 ADVANCED DATA

FORMATTING

Introduction

Advanced Data Formatting (ADF) is a means of customizing data before transmission to the host device. Use ADF

to edit scan data to suit requirements. Implement ADF by scanning a related series of bar codes which program the

scanner with ADF rules.

For information and programming bar codes for ADF, refer to the Advanced Data Formatting Programmer Guide,

p/n 72E-69680-xx.
