Zebra DS3608 Product Reference Guide

SSI Interface 7 - 11
SSI Host Parameters
Select SSI Host
To select SSI as the host interface, scan the following bar code.
Host Character Time-out 239 EFh 200 msec 7-18
Multipacket Option 334 F0h 4Eh Option 1 7-19
Interpacket Delay 335 F0h 4Fh 0 ms 7-20
Event Reporting
Decode Event 256 F0h 00h Disable 7-21
Boot Up Event 258 F0h 02h Disable 7-22
Parameter Event 259 F0h 03h Disable 7-22
Table 7-3 SSI Default Table (Continued)
Parameter
Parameter
Number
SSI
Number
Default
Page
Number
NOTE SSI interprets Prefix, Suffix1, and Suffix2 values listed in Table H-1 on page H-1 differently than other
interfaces. SSI does not recognize key categories, only the 3-digit decimal value. The default value of
7013 is interpreted as CR only.
SSI Host

Zebra DS3608 Specifications

General

Type	Handheld bar code reader
Wavelength	655 nm
Sensor type	Laser
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 65 °
Light levels (direct sunlight)	0 - 108000 lx
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 39, Code 93, EAN 128, EAN 2, EAN 5, EAN-13, EAN-8, GS1 DataBar, Industrial 2 of 5, MSI, U.P.C., UPC-A, UPC-E
Optical sensor resolution (W x H)	1280 x 960 pixels
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code, TLC-39
Input voltage	4.5 - 5.5 V
Power source type	RS-232, USB
Certification	RoHS EN 50581: 2012
Product color	Black, Grey
LED indicators	Yes
International Protection (IP) code	IP65
Standard interfaces	Keyboard wedge, RS-232, USB
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	132 mm
Width	77 mm
Height	185 mm
Weight	304 g
