Zebra DS3608 Product Reference Guide

12 - 18 DS3608 Digital Scanner Product Reference Guide
IDC Demonstrations
Anchored Mode Demo
Set parameters to these values:
• Pull the trigger. The decoder decodes the bar code and captures an image of the text scroll.
• Rotate the form clockwise so the word Capture is along the bottom edge, and pull the trigger. The decoder
decodes the bar code and captures the same image, including orientation. (This example also works with the
form rotated counterclockwise or upside down).
• Modify the values for height, width, x, and y. Pull the trigger. The captured area changes in size and location.
• Cover the bar code with a small piece of paper (or your finger) and pull the trigger. The decoder does not
decode the bar code or capture an image.
What this demonstrates:
The Intelligent Document Capture Anchored mode captures an image of fixed size and location relative to a
bar code on the page. Parameters control the height, width, and location. The IDC firmware requires that a bar
code is present in order to capture an image, decodes it, and uses it to adjust the image to the upright
orientation.
Free-Form Mode Demo
Set IDC Operating Mode to Free-Form.
• Pull the trigger. The decoder decodes the bar code and captures an image of the entire rectangle, including
the contents.
• Modify the values for height, width, x, and y. Pull the trigger. Note that the captured image is not affected.
• Rotate the form clockwise so the word Capture is along the bottom edge, and pull the trigger. The decoder
decodes the bar code and captures the same image, including orientation. (This example also works with the
form rotated counterclockwise or upside down).
• Cover the bar code with a small piece of paper and pull the trigger. The decoder does not decode the bar
code and does not re-orient the captured image to the normal position, i.e., with the logo in upper-left corner.
What this demonstrates:
The Intelligent Document Capture Free-Form mode captures an image whose size and position are
determined by a rectangular border on the page. It adjusts the image to the upright orientation if a bar code is
found and decoded in the image.
Table 12-3 Anchored Mode Sample Parameter Values
Parameter Value
IDC Operating Mode Anchored
IDC Height 100
IDC Width 90
IDC X Coordinate -175
IDC Y Coordinate -50

Zebra DS3608 Specifications

General

Type	Handheld bar code reader
Wavelength	655 nm
Sensor type	Laser
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 65 °
Light levels (direct sunlight)	0 - 108000 lx
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 39, Code 93, EAN 128, EAN 2, EAN 5, EAN-13, EAN-8, GS1 DataBar, Industrial 2 of 5, MSI, U.P.C., UPC-A, UPC-E
Optical sensor resolution (W x H)	1280 x 960 pixels
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code, TLC-39
Input voltage	4.5 - 5.5 V
Power source type	RS-232, USB
Certification	RoHS EN 50581: 2012
Product color	Black, Grey
LED indicators	Yes
International Protection (IP) code	IP65
Standard interfaces	Keyboard wedge, RS-232, USB
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	132 mm
Width	77 mm
Height	185 mm
Weight	304 g
