12 - 4 DS3608 Digital Scanner Product Reference Guide
Parameters
This section describes the parameters controlling the IDC firmware and provides programming bar codes for
setting them.
To set parameters requiring a range of values, scan the parameter bar code followed by two, three, or four bar
codes from Appendix G, Numeric Bar Codes corresponding to the desired value. Scan two numeric bar codes for
parameters with a maximum value of less than 100, for example, IDC Minimum Text Length. IDC Delay Time
requires scanning three digits since the maximum value is 200. Leading zeros are required.
Alternatively, use the sample application to set parameters using the parameter name. The application provides
prompts and error checking to assist in setting the parameters correctly and easily. You must use an application to
set a parameter to a negative value, as the IDC X Coordinate can require.
Table 12-1 Intelligent Document Capture (IDC) Parameter Defaults
Parameter Parameter Name
Parameter
Number
SSI Number Default
Page
Number
Intelligent Document Capture (IDC)
IDC Operating Mode
DocCap_MODE 594 F1h 52h Off 12-5
IDC Symbology DocCap_SYMBOLOGY 655 F1h 8Fh 001 12-6
IDC X Coordinate DocCap_X 596 F4h F1h 54h -151 12-7
IDC Y Coordinate DocCap_Y 597 F4h F1h 55h -050 12-7
IDC Width DocCap_WIDTH 598 F1h 56h 0300 12-8
IDC Height DocCap_HEIGHT 599 F1h 57h 0050 12-8
IDC Aspect DocCap_ASPECT 595 F1h 53h 000 12-9
IDC File Format Selector DocCap_FMT 601 F1h 59h JPEG 12-9
IDC Bits Per Pixel DocCap_BPP 602 F1h 5Ah 8 BPP 12-10
IDC JPEG Quality DocCap_JPEG_Qual 603 F1h 5Bh 065 12-10
IDC Find Box Outline Sig_FINDBOX 727 F1h D7h Disable 12-11
IDC Minimum Text Length DocCap_MIN_TEXT 656 F1h 90h 00 12-11
IDC Maximum Text Length DocCap_MAX_TEXT 657 F1h 91h 00 12-12
IDC Captured Image
Brighten
Sig_BRIGHTEN 654 F1h 8Eh Enable 12-12
IDC Captured Image
Sharpen
Sig_SHARPEN 658 F1h 92h Enable 12-13
IDC Border Type DocCap_BORDER 829 F2h 3Dh None 12-14
IDC Delay Time DocCap_DELAY 830 F2h 3Eh 000 12-15
IDC Zoom Limit Sig_MIN_PERCENT 651 F1h 8Bh 000 12-15
IDC Maximum Rotation Sig_MAX_ROT 652 F1h 8Ch 00 12-16

Zebra DS3608 Specifications

General

Type	Handheld bar code reader
Wavelength	655 nm
Sensor type	Laser
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 65 °
Light levels (direct sunlight)	0 - 108000 lx
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 39, Code 93, EAN 128, EAN 2, EAN 5, EAN-13, EAN-8, GS1 DataBar, Industrial 2 of 5, MSI, U.P.C., UPC-A, UPC-E
Optical sensor resolution (W x H)	1280 x 960 pixels
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code, TLC-39
Input voltage	4.5 - 5.5 V
Power source type	RS-232, USB
Certification	RoHS EN 50581: 2012
Product color	Black, Grey
LED indicators	Yes
International Protection (IP) code	IP65
Standard interfaces	Keyboard wedge, RS-232, USB
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	132 mm
Width	77 mm
Height	185 mm
Weight	304 g
