12 - 10 DS3608 Digital Scanner Product Reference Guide
IDC Bits Per Pixel
Parameter Name: DocCap_BPP
Parameter # 602 (SSI # F1h 5Ah)
Select the number of significant bits per pixel (BPP) to use when capturing an image. Select 1 BPP for a black and
white image, 4 BPP to assign 1 of 16 grey levels to each pixel, or 8 BPP to assign 1 of 256 levels of grey to each
pixel.
IDC JPEG Quality
Parameter Name: DocCap_JPEG_Qual
Parameter # 603 (SSI # F1h 5Bh)
Set the amount of JPEG compression to perform on the captured image. Higher numbers produce a better quality
image but larger files.
Scan the bar code below, followed by three bar codes from Appendix G, Numeric Bar Codes in the range of 005 to
100 decimal. The default is 065.
NOTE The decoder ignores these settings for JPEG file formats, which only support 8 BPP.
1 BPP
(0)
4 BPP
(1)
*8 BPP
(2)
IDC JPEG Quality
To Next Page
