Zebra DS3608 Product Reference Guide

2 - 8 DS3608 Digital Scanner Product Reference Guide
Decode Ranges
Table 2-2 DS3608-HD Decode Ranges
Bar Code
Type
Symbol
Density
DS3608-HD
Typical Working Ranges
Near Far
Code 128 5.0 mil 0.9 in. / 2.3 cm 7.0 in / 17.8 cm
15.0 mil 0.9 in. / 2.3 cm 23 in. / 58.4 cm
Code 39 3.0 mil 1.3 in / 3.3 cm 4.7 in / 11.9 cm
20.0 mil 0.25 in / 0.6 cm 34.0 in / 86.3 cm
100% UPC 13.0 mil 0.25 in / 0.6 cm 22.0 in / 55.8 cm
PDF 417 5.0 mil 2.0 in. / 5.1 cm 6.0 in. / 15.2 cm
6.6 mil 0.9 in. / 2.3 cm 9.0 in. / 22.8 cm
Data Matrix 10.0 mil 1.0 in. / 2.5 cm 9.0 in. / 22.8 cm
Table 2-3 DS3608-HP Decode Ranges
Bar Code
Type
Symbol
Density
DS3608-HP
Typical Working Ranges
Near Far
Code 128 5.0 mil 6.0 in / 15.2 cm 14.0 in / 35.5 cm
Code 39 20.0 mil 2.0 in / 5.1 cm 43.0 in / 109 cm
100% UPC 13.0 mil 1.1 in / 2.8 cm 36.0 in / 91.0 cm
PDF 417 5.0 mil 8.0 in / 20.3 cm 11.5 in / 29.2 cm
Data Matrix 7.5 mil 7.0 in / 17.8 cm 11.0 in / 27.9 cm
10.0 mil 6.0 in / 15.2 cm 15.0 in / 38.1 cm

Zebra DS3608 Specifications

General

Type	Handheld bar code reader
Wavelength	655 nm
Sensor type	Laser
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 65 °
Light levels (direct sunlight)	0 - 108000 lx
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 39, Code 93, EAN 128, EAN 2, EAN 5, EAN-13, EAN-8, GS1 DataBar, Industrial 2 of 5, MSI, U.P.C., UPC-A, UPC-E
Optical sensor resolution (W x H)	1280 x 960 pixels
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code, TLC-39
Input voltage	4.5 - 5.5 V
Power source type	RS-232, USB
Certification	RoHS EN 50581: 2012
Product color	Black, Grey
LED indicators	Yes
International Protection (IP) code	IP65
Standard interfaces	Keyboard wedge, RS-232, USB
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	132 mm
Width	77 mm
Height	185 mm
Weight	304 g
