Zebra DS3608 Product Reference Guide

Maintenance & Technical Specifications 3 - 7
Technical Specifications
Table 3-2 Technical Specifications
Item Description
Physical Characteristics
Dimensions
DS3608 7.3 in. H x 3.0 in. W x 5.2 in. D
(18.5 cm H x 7.7 cm W x 13.2 cm D)
Weight
(without cable)
DS3608-SR
DS3608-HP
DS3608-HD
Approximately 10.76 oz./305 g
Approximately 10.9 oz./309 g
Approximately 10.9 oz./309 g
Power 5 VDC +/- 10% @ 360 mA (RMS typical)
Performance Characteristics
Light Source
DS3608-SR
DS3608-HP
DS3608-HD
Aiming pattern: 610 nm LED / Illumination: 660 nm LEDs
Aiming pattern: 655 nm Laser / Illumination: Warm white LEDs
Aiming pattern: 655 nm Laser / Illumination: Warm white LEDs
Field of View
(Horizontal x Vertical)
Nominal
DS3608-SR
DS3608-HP
DS3608-HD
42º (H) x 28º (V)
31º (H) x 23º (V)
48º (H) x 36.7º (V)
Roll
Pitch
Yaw
0 - 180º
+/- 60º
+/- 60º
Symbology Decode Capability
1D UPC/EAN, UPC/EAN with supplementals, Bookland EAN, ISSN, UCC Coupon
Extended Code, Code 128, GS1-128, ISBT 128, ISBT Concatenation, Code 39,
Code 39 Full ASCII, Trioptic Code 39, Code 32, Code 93, Code 11, Interleaved 2
of 5, Discrete 2 of 5, Codabar, MSI, Chinese 2 of 5, Matrix 2 of 5, Korean 3 of 5,
GS1 DataBar variants
2D PDF417, MicroPDF417, Composite Codes, TLC-39, Data Matrix, Maxicode,
QR Code, MicroQR, Aztec, Han Xin, GS1-QR, GS1-DM
Postal US Postnet, US Planet, UK Postal, Japan Post, Australia Post, Royal Mail 4 State
Customer, KIX Code (Dutch), UPU 4 State Postal FICS (Post US4), USPS 4
State Postal (Post US3)
Typical Working Distance See
Decode Ranges on page 2-8 .

Zebra DS3608 Specifications

General

Type	Handheld bar code reader
Wavelength	655 nm
Sensor type	Laser
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 65 °
Light levels (direct sunlight)	0 - 108000 lx
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 39, Code 93, EAN 128, EAN 2, EAN 5, EAN-13, EAN-8, GS1 DataBar, Industrial 2 of 5, MSI, U.P.C., UPC-A, UPC-E
Optical sensor resolution (W x H)	1280 x 960 pixels
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code, TLC-39
Input voltage	4.5 - 5.5 V
Power source type	RS-232, USB
Certification	RoHS EN 50581: 2012
Product color	Black, Grey
LED indicators	Yes
International Protection (IP) code	IP65
Standard interfaces	Keyboard wedge, RS-232, USB
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	132 mm
Width	77 mm
Height	185 mm
Weight	304 g
