Zebra DS3608 Product Reference Guide

3 - 8 DS3608 Digital Scanner Product Reference Guide
Interfaces Supported USB, RS-232, RS-485 (IBM 46xx), keyboard wedge, SSI
The scanner supports the following protocols over USB: HID Keyboard (default
mode), SNAPI, COM Port Emulation, IBM SurePOS (Yellowstone) (IBM
Hand-held, IBM Table-top, OPOS), USB CDC, SSI over USB CDC
The scanner supports the following protocols over RS232: Standard,
Wincor-Nixdorf, ICL, Fujitsu, Olivetti, Omron, CUTE
Minimum Resolution
DS3608-HD
DS3608-HP
DS3608-SR
Code 39 3 mil
UPC 40% 5.2 mil
PDF417 5 mil
Data Matrix 6 mil
Code 39 3 mil
UPC 40% 5.2 mil
PDF417 5 mil
Data Matrix 7.5 mil
Code 39 4 mil
UPC 60% 7.8 mil
PDF417 5 mil
Data Matrix 7.5 mil
User Environment
Operating Temperature -22° F to 122°F (-30° C to 50° C)
Storage Temperature -40º F to 158º F (-40º C to 70º C)
Humidity 5 % to 95 % RH, non-condensing
Drop Specifications
DS3608 Withstands multiple 8 ft / 2.4 m drops to concrete at room temperature.
Withstands multiple 6.5 ft / 2.0 m drops to concrete at -30° C to 50° C
Environmental Sealing IP65 and IP67
Ambient Light Immunity Immune to normal indoor lighting up to 1600 Lux.
Immune to sunlight up to 86,000 Lux.
Accessories
DS3608 Hands-Free
Option
Intellistand
Power Supplies Power supplies are available for applications that do not supply power over the
host cable.
Table 3-2 Technical Specifications (Continued)
Item Description

Zebra DS3608 Specifications

General

Type	Handheld bar code reader
Wavelength	655 nm
Sensor type	Laser
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 65 °
Light levels (direct sunlight)	0 - 108000 lx
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 39, Code 93, EAN 128, EAN 2, EAN 5, EAN-13, EAN-8, GS1 DataBar, Industrial 2 of 5, MSI, U.P.C., UPC-A, UPC-E
Optical sensor resolution (W x H)	1280 x 960 pixels
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code, TLC-39
Input voltage	4.5 - 5.5 V
Power source type	RS-232, USB
Certification	RoHS EN 50581: 2012
Product color	Black, Grey
LED indicators	Yes
International Protection (IP) code	IP65
Standard interfaces	Keyboard wedge, RS-232, USB
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	132 mm
Width	77 mm
Height	185 mm
Weight	304 g
