1 - 4 DS3608 Digital Scanner Product Reference Guide
4. Tighten lock plate screw using a PH1 driver (recommended Torque: 5 in-lbs).
Figure 1-5 Tightening Lock Plate
Removing the DS3608 Interface Cable
1. Loosen lock plate screw using a PH1 driver.
Figure 1-6 Loosening Lock Plate
2. Slide lock plate to fully unlocked position.
Figure 1-7 Sliding Lock Plate into Unlocked Position
