Zebra DS3608 Product Reference Guide

xx DS3608 Digital Scanner Product Reference Guide
Related Product Line Configurations
The product configurations related to the DS3608 digital scanner are as follows:
NOTE Check Solution Builder for:
- additional information regarding all available accessories
- - the latest available configurations.
Product Part Number Description
Accessories
Intellistand STND-AS0036-07 Stand: Adjustable Intellistand, Black
Tool Balancer Pulley 50-15400-031 Pulley: Tool Balancer Pulley
Clip on Belt Holster 11-59382-01 Holder: Clip on Belt
Fork Lift Holder
21-52612-01R Holder: Fork Lift
Lanyard
50-12500-066 Lanyard Strap
Universal Cables
Shielded USB
CBA-U70-C127ZAR Shielded USB: Series A Locking Connector for VC70, 12', Coiled, -30C
CBA-U42-S07PAR Shielded USB: Series A Connector, 7ft. (2.8m), Straight, 12V (Requires 12V
Power Supply)
CBA-U46-S07ZAR Shielded USB: Series A Connector, 7ft. (2m), Straight, BC 1.2
CBA-U47-S15ZAR Shielded USB: Series A Connector, 15ft. (4.6m), Straight, BC 1.2
CBA-U48-C15PAR Shielded USB: Series A Connector, 15ft. (4.6m), Coiled, 12V (Requires 12V
Power Supply
CBA-U49-C15ZAR Shielded USB: Series A Connector, 15ft. (4.6m), Coiled, BC 1.2
CBA-U43-S07ZAR Shielded USB: Power Plus Connector, 7ft. (2.8m), Straight, 12V
CBA-UF0-S07PAR Cable - Shielded USB: Series A Connector, 7ft. (2m), Straight, 12V (Requires
12V Power Supply), Low Temp -30C
CBA-UF1-S07ZAR Cable - Shielded USB: Series A Connector, 7ft. (2m), Straight, BC 1.2 (High
Current), -30C
Keyboard Wedge
CBA-K63-S07PAR Auto-Host Detect - Keyboard Wedge: 7ft. (2m) Straight, PS/2 Power Port, 12V
(Requires 12V Power Supply)
IBM
CBA-M65-S07ZAR Auto-Host Detect - IBM: 468x/9x, 7ft (2m) Straight, Port 9B, 12V
RS-232
CBA-R07-S07PAR RS232: DB9 Female Connector, 7 ft. (2m) Straight, TxD on 2, 12V (Requires
12V Power Supply)
CBA-RF0-S07PAR RS232: DB9 Female Connector, 9ft. (2.8m) Coiled, TxD on 2, 12V (Requires
12V Power Supply)
CBA-RF1-C09PAR Cable - RS232: DB9 Female Connector, 9ft. (2.8m) Coiled, TxD on 2, 12V
(Requires 12V Power Supply), -30C
CBA-RF2-C09ZAR Cable - RS232: DB9 Female Connector, 9ft (2.8m) Coiled, Power Pin 9, -30C
CBA-RF3-C09ZAR Cable - RS232: DB9 Female Connector, 9ft. (2.8m) Coiled, Power Pin 9, TxD
on 2, True Converter, Low Temp -30C
Power Supplies
PWRS-14000-148R Power Supply: 100-240 VAC, 12VDC, 4.16A
PWRS-14000-251 Power Supply: 18-75VDC, 12VDC, High
PWRS-14000-252 Power Supply: 9-30VDC, 12VDC, Low

Zebra DS3608 Specifications

General

Type	Handheld bar code reader
Wavelength	655 nm
Sensor type	Laser
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 65 °
Light levels (direct sunlight)	0 - 108000 lx
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 39, Code 93, EAN 128, EAN 2, EAN 5, EAN-13, EAN-8, GS1 DataBar, Industrial 2 of 5, MSI, U.P.C., UPC-A, UPC-E
Optical sensor resolution (W x H)	1280 x 960 pixels
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code, TLC-39
Input voltage	4.5 - 5.5 V
Power source type	RS-232, USB
Certification	RoHS EN 50581: 2012
Product color	Black, Grey
LED indicators	Yes
International Protection (IP) code	IP65
Standard interfaces	Keyboard wedge, RS-232, USB
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	132 mm
Width	77 mm
Height	185 mm
Weight	304 g
