13 - 2 DS3608 Digital Scanner Product Reference Guide
Table 13-1 OCR Programming Default Table
Parameter
Parameter
Number
SSI Number Default Page Number
OCR Programming Parameters
OCR-A 680 F1h A8h Disable 13-3
OCR-A Variant 684 F1h ACh Full ASCII 13-3
OCR-B 681 F1h A9h Disable 13-5
OCR-B Variant 685 F1h ADh Full ASCII 13-6
MICR E13B 682 F1h AAh Disable 13-9
US Currency 683 F1h ABh Disable 13-10
OCR Orientation 687 F1h AFh
0
o
13-10
OCR Lines 691 F1h B3h 1 13-12
OCR Minimum Characters 689 F1h B1h 3 13-12
OCR Maximum Characters 690 F1h B2h 100 13-13
OCR Subset 686 F1h AEh Selected font
variant
13-13
OCR Quiet Zone 695 F1h B7h 50 13-14
OCR Template 547 F1h 23h 54R 13-15
OCR Check Digit Modulus 688 F1h B0h 1 13-25
OCR Check Digit Multiplier 700 F1h BCh 121212121212 13-26
OCR Check Digit Validation 694 F1h B6h None 13-27
Inverse OCR 856 F2h 58h Regular 13-32

Zebra DS3608 Specifications

General

Type	Handheld bar code reader
Wavelength	655 nm
Sensor type	Laser
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 65 °
Light levels (direct sunlight)	0 - 108000 lx
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 39, Code 93, EAN 128, EAN 2, EAN 5, EAN-13, EAN-8, GS1 DataBar, Industrial 2 of 5, MSI, U.P.C., UPC-A, UPC-E
Optical sensor resolution (W x H)	1280 x 960 pixels
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code, TLC-39
Input voltage	4.5 - 5.5 V
Power source type	RS-232, USB
Certification	RoHS EN 50581: 2012
Product color	Black, Grey
LED indicators	Yes
International Protection (IP) code	IP65
Standard interfaces	Keyboard wedge, RS-232, USB
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	132 mm
Width	77 mm
Height	185 mm
Weight	304 g
