Data Capture 2 - 3
ADF Programming
Enter another digit. Add leading zeros to the front if
necessary.
High, Low beeps Green
Enter another alphabetic character or scan the End
of Message bar code.
Low, Low beeps Green
ADF criteria or action is expected. Enter another
criterion or action, or scan the Save Rule bar code.
High, High beeps Green Blinking
Rule saved. Rule entry mode exited.
High, Low, High, Low beeps Green (turns off blinking)
All criteria or actions cleared for current rule,
continue entering rule.
High, Low, Low beeps Green
Delete last saved rule. The current rule is left intact.
Low beep Green
All rules are deleted.
Low, High, High beeps Green
Out of rule memory. Erase some existing rules, then
try to save rule again
Low, High, Low, High beeps Red
Cancel rule entry. Rule entry mode exited because
of an error or the user asked to exit rule entry.
Low, High, Low beeps Green
(turns off blinking)
Entry error, wrong bar code scanned, or
criteria/action list is too long for a rule. Re-enter
criterion or action.
Low, High beeps Red
Macro PDF
File ID error. A bar code not in the current MPDF
sequence was scanned.
2 Low
beeps None
File ID error. A bar code not in the current MPDF
sequence was scanned.
2 Long Low
beeps None
Out of memory. There is not enough buffer space to
store the current MPDF symbol.
3 Long Low
beeps None
Bad symbology. Scanned a 1D or 2D bar code in a
MPDF sequence, a duplicate MPDF label, a label in
an incorrect order, or trying to transmit an empty or
illegal MPDF field.
4 Long Low
beeps None
Flushing MPDF buffer.
5 Long Low
beeps None
Aborting MPDF sequence.
Fast Warble None
Flushing an already empty MPDF buffer.
Low, High
beeps None
Maintenance Indications
Enter Bootloader
High, High
beeps Red (stays on)
Firmware Installation None Red Blinking
Table 2-1 Beeper and LED Indicators (Continued)
Event Beeper Sequence LED Indicator
