Zebra DS3608 Product Reference Guide

User Preferences & Miscellaneous Options 4 - 3
Decode Pager Motor 613 F1h 65h Enable 4-12
Decode Pager Motor Duration 626 F1h 72h 150 msec 4-12
Low Power Mode 128 80h Disable 4-14
Time Delay to Low Power Mode 146 92h 1 Hour 4-15
Hand-Held Trigger Mode 138 8Ah Level 4-17
Hands-Free Mode 630 F1h 76h Enable 4-18
Hand-Held Decode Aiming Pattern 306 F0h 32h Enable 4-19
Hands-Free (Presentation) Decode
Aiming Pattern
590 F1h 4Eh Enable Hands-Free
(Presentation) Decode
Aiming Pattern on PDF
4-20
Picklist Mode 402 F0h 92h Disabled Always 4-21
Continuous Bar Code Read 649 F1h 89h Disable 4-22
Unique Bar Code Reporting 723 F1h D3h Enable 4-22
Decode Session Timeout 136 88h 9.9 Sec 4-23
Hands-Free Decode Session Timeout 400 F0h 90h 15 4-24
Timeout Between Decodes, Same
Symbol
137 89h 0.5 Sec 4-25
Timeout Between Decodes, Different
Symbols
144 90h 0.1 sec 4-26
Decode Mirror Images (Data Matrix Only) 537 F1h 19h Auto 4-27
Mobile Phone/Display Mode 716 F1h CCh Normal 4-28
PDF Prioritization 719 F1h CFh Disable 4-29
PDF Prioritization Timeout 720 F1h D0h 200 ms 4-30
Presentation Mode Field of View 609 F1h 61h Full 4-31
Decoding Illumination 298 F0h 2Ah Enable 4-32
Motion Tolerance (Hand-Held Trigger
Mode Only)
858 F2h 5Ah Less Motion Tolerance 4-33
Table 4-1 User Preferences Parameter Defaults (Continued)
Parameter
Parameter
Number
1
SSI
Number
2
Default
Page
Number
1. Parameter number decimal values are used for programming via RSM
commands.
2. SSI number hex values are used for programming via SSI commands.

Zebra DS3608 Specifications

General

Type	Handheld bar code reader
Wavelength	655 nm
Sensor type	Laser
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 65 °
Light levels (direct sunlight)	0 - 108000 lx
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 39, Code 93, EAN 128, EAN 2, EAN 5, EAN-13, EAN-8, GS1 DataBar, Industrial 2 of 5, MSI, U.P.C., UPC-A, UPC-E
Optical sensor resolution (W x H)	1280 x 960 pixels
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code, TLC-39
Input voltage	4.5 - 5.5 V
Power source type	RS-232, USB
Certification	RoHS EN 50581: 2012
Product color	Black, Grey
LED indicators	Yes
International Protection (IP) code	IP65
Standard interfaces	Keyboard wedge, RS-232, USB
Connectivity technology	Wired
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	132 mm
Width	77 mm
Height	185 mm
Weight	304 g
