Zebra LI4278 Product Reference Guide

USER PREFERENCES & MISCELLANEOUS SCANNER OPTIONS 5 - 3
Time Delay to Low Power Mode 146 100 msec 5-11
Time Delay to Presentation Sleep Mode 662 5 Min 5-12
Timeout to Low Power Mode from Auto Aim 729 15 sec 5-14
Continuous Bar Code Read 649 Disable 5-15
Unique Bar Code Reporting 723 Disable 5-15
Decode Session Timeout 136 9.9 sec 5-16
Timeout Between Decodes, Same Symbol 137 0.5 sec 5-16
Timeout Between Decodes, Different Symbols 144 0.2 sec 5-16
Decoding Illumination 298 Enable 5-17
Miscellaneous Options
Transmit Code ID Character 45 None 5-18
Prefix Value 99, 105 7013 <CR><LF> 5-19
Suffix 1 Value
Suffix 2 Value
98, 104
100, 106
7013 <CR><LF> 5-19
Scan Data Transmission Format 235 Data as is 5-20
FN1 Substitution Values 103, 109 Set 5-21
Transmit “No Read” Message 94 Disable 5-22
Unsolicited Heartbeat Interval 1118 Disable 5-23
Dump Scanner Parameters 5-24
Parameter
Parameter
Number
Default
Page
Number

Zebra LI4278 Specifications

General

Wavelength	617 nm
Read rate (max)	547 reads/s
Decoding standards	UPC/EAN, UPC-A, UPC-E, UPC-E1, EAN-8/JAN 8, EAN-13/JAN 13, Bookland EAN, Bookland ISBN, UCC Coupon, ISBT 128, Code 39, Code 93, Matrix 2/5, Interleavd 2/5, Discrete 2/5, Codabar, MSI Chinese 2/5, GS1
Pitch reading angle	-65 - 65 °
Light levels (direct sunlight)	0 - 108000 lx
Bluetooth	Yes
Bluetooth version	2.1+EDR
Standard interfaces	USB, RS-232, RS-485
Operating time	4320 min
Maximum operating distance	100 m
Certification	FCC, ICES, IEC, RoHS, EN, UL
Product color	Black
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 85 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	186 mm
Width	70 mm
Height	98 mm
Weight	224 g
